Altec LASSIE2 Plus - Page 226

226
Wristband/roll paper (WB-M series)
When “Borderless Printing“ is disabled
Top, bottom, left. right margins: 1.5 mm (Typical value)
 Do not print inside or within 2 mm {0.08"} around the snap button mounting hole to pre-
vent damage to the mechanical functions.
 If using the WB-S/M/L series, use the attachment (OT-WA34).
Paper width
1.5 mm
Autocutting position
Center of paper width
Print area
1.5 mm
Paper
Paper feeding direction
5.5 mm
11.0 mm
1.5 mm
Recommended print area for text
and barcodes (*dimension)
1.5 mm
30.6 mm
292.1 mm
156.5 mm
105.0 mm
15.0 mm
265.0 mm
14.6 mm
12.5 mm
138.9 mm
142.4 mm
Autocutting position
10.8 mm
36 mm
