152 KE/KX/KG (RIGID) BAH0089-7 02.2020
12.5.2 Greasing points – overview
Lubrication
points
(see Figure)
Number of
grease
nipples
Lubrication interval Note
Fig. 171/1 1 50 h
Lubricate the universal joint shaft,
referring to the universal joint manu-
facturer's maintenance schedule.
Grease the protective tubes and
profile tubes.
Greasing the protective tubes pre-
vents them from freezing.
Open the profile tubes for lubrica-
tion.
Fig. 171/2 1 50 h
Fig. 171/3 1 50 h
Fig. 172/1 2 25 h Track marker
Fig. 173/1 2
 every 500 operating hours
 before an extended idle
period
Side panel
Fig. 174/1 2
 every 500 operating hours
 before an extended idle
period
Levelling board
Fig. 175 4 50 h
Side plate, sliding
The linch pins (Fig. 175/1) and co-
vers (Fig. 175/2) are opened for
better understanding.
Fig. 176/1 to 6 10 50 h Lifting frame 2.2
Fig. 177/1 to 6 10 50 h Lifting frame 3.2
