Structure and function
KE/KX/KG (RIGID) BAH0089-7 02.2020
77
5.10.3
Side panel, spring-mounted
The spring-mounted
side panel (Fig
.
57/1)
moves aro
und obstac
les.
Two tension springs bri
ng the side panel back to
the working position.
Fig. 57
5.11
Soil guiding angl
e bracket (optional)
Free-flowing soil can e
s
cape between the side
panel and the roller, even whe
n adjusted correct-
ly. The soil guiding angle bracket (Fig. 58/1) p
re-
vents the soil from escaping.
Fig. 58
76
78
