Structure and function
KE/KX/KG (RIGID) BAH0089-7 02.2020
79
5.14
Combination possibilities wi
th other AMAZONE implements
5.14.1
Lifting frame
The soil tillage implement can be combi
ned with
a mounted seed drill with
the aid of the lifting
frame (Fig. 62).
This operating manual describes how to
couple
the mounted seed drill (see section 5.15, page
81).
Fig. 62
78
80
