Structure and function
80 KE/KX/KG (RIGID) BAH0089-7 02.2020
5.14.2 QuickLink
The soil tillage implement can be combined with
an AMAZONE pack top seed drill with the aid of
the QuickLink mount (Fig. 63/1).
Fig. 63
The distance between the inner edge of the
mounting points (Fig. 64/A) depends on the
working width of the seeding combination.
Fig. 64
Working width [m] Distance A [mm]
2.5 1529 ±3
3.0 2029 ±3
3.5 2529 ±3
4.0 3029 ±3
Soil tillage implement in combination with a
Pack-top seed drill, mechanical
(Fig.65/1)
Pack-top seed drill, pneumatic
(Fig. 66)
Deep loosener (not shown)
Fig.65
Fig. 66
Use of a rotary harrow in combina-
tion with the Centaya pack top seed
drill is not permitted!
Additional information via Customer
Service / Dealers.
