Cleaning, maintenance and repai
158 KE/KX/KG (RIGID) BAH0089-7 02.2020
12.9 WHG/KG Special / Super gearbox
12.9.1 Venting
The dipstick is equipped with a ventilation valve.
Ventilation must be ensured to prevent the gearbox from developing
leaks.
12.9.2 Check the oil level
1. Park the implement on a level surface.
2. Check the oil level with the dipstick.
Fig. 180
At the correct fill level, the oil level reaches
between the markings on the dipstick.
3. If necessary, top up the transmission fluid
through the opening for the dipstick.
12.9.3 Changing transmission fluid (specialist workshop)
1. Place a suitable container below the oil
drain opening.
2. Unscrew the oil drain screw (Fig. 180/1).
3. Collect the transmission fluid and dispose of
it properly.
4. Screw in the oil drain screw.
5. Refill with new transmission fluid
(for oil types and fill quantities, see the
section "Technical Data").
6. Screw in the dipstick.
