AMD Vega 10 - Pins Sorted by Signal Name; Table A-2 Pins Sorted by Signal Name

Ball Reference Signal Name
BE31 CTF
BE32 RSVD
BE33 PUMPIN
BE34 VSS
BE35 RSVD
BE36 RSVD
BE37 VSS
BE38 RSVD
BE39 VSS
BE40 RSVD
BE42 VSS
BE43 VSS
BE44 VSS
A.2 Pins Sorted by Signal Name
Table A–2 Pins Sorted by Signal Name
Signal Name Ball Reference
ALERT_L BD31
ANALOGIO AJ7
AUX1N G5
AUX1P G4
AUX2N K3
AUX2P K2
AUX_ZVSS P5
BL_ENABLE AU14
BL_PWM_DIM AV16
BP_0 AR1
BP_1 AR2
BP_2 AT2
BP_3 AT1
CLKREQB BE3
CTF BE31
DBREQ_L AM9
DDC1CLK F6
DDC1DATA F5
DDC2CLK J5
DDC2DATA J4
DDCAUX3N R5
DDCAUX3P R4
DDCAUX4N W5
