AMD Vega 10 User Manual

5
Electrical Characteristics
This chapter describes the electrical characteristics of "Vega 10".
All voltages are with respect to VSS unless specified otherwise.
To link to a topic of interest, use the following list of linked cross-references:
• Maximum Voltage (p. 57)
• Electrical Design Power (p. 58)
• Power-up/down Sequence (p. 61)
• TTL Interface Electrical Characteristics (p. 61)
• DDC I2C Mode Electrical Characteristics (p. 61)
• DisplayPort AUX Electrical Specification (p. 62)
• DisplayPort Main Link Electrical Characteristics (p. 63)
• SMBus Electrical Characteristics (p. 63)
5.1 Maximum Voltage
Note: In the below table, the VDDCR_SOC voltage and VDDCR_HBM/VDDIO_MEM
voltage are defined as the command voltage sent by the GPU to the SVI2 voltage
regulator through SVD data packets. The voltage for other power rails is defined at
the respective power balls of the GPU. Any stress voltage greater than the absolute
maximum in the table may cause permanent dmage to the device, or adversely affect
the device reliability.
Table 5–1 Maximum Voltage
Supply Maximum Voltage
VDDCR_SOC
1.25 V
VDDCI_MEM
0.954 V
VDDAN_33
3.630 V
VDDCR_HBM
1.38 V
VDDIO_MEM
VDD_08
0.945 V
VDDCR_BACO
VDD_080_EFUSE
VPP
2.75 V
VDD_18
1.980 V
VDDAN_18
VDDAN_Q_EFUSE
© 2017 Advanced Micro Devices, Inc.
AMD Confidential - Do not duplicate.
"Vega 10" Databook
56006_1.00

AMD Vega 10 Specifications

General

Process Size	14 nm
Transistor Count	12.5 billion
Memory Type	HBM2
GPU	Vega 10
Stream Processors	4096
Texture Units	256
ROPs	64
Memory Size	8 GB
Die Size	486 mm²
Memory Bandwidth	483.8 GB/s
Compute Units	64
FP32 (float) Performance	12.66 TFLOPS
Memory Bus	2048-bit
