Table 7–1 Recommended Profiling — RoHS/Lead-Free Solder
Profiling Stage Temperature Process Range
Overall Preheat
Room temperature to 220℃
Two to four minutes
Soaking Time
130℃ to 170℃
Typically 60 to 80 seconds
Liquidus
220℃
Typically 60 to 80 seconds
Ramp Rate
Ramp up
Ramp down
< 2℃ / second
< 1℃ / second
Peak
Maximum 245℃ 235℃ ± 5℃
Temperature at Peak Within 5℃
240℃ to 245℃
10 to 30 seconds
