Symbol Description Min Max Unit Notes
VIL
DC
Maximum DC voltage at the PAD pin that will produce a stable low
at the Y pin of the macro.
— 0.8 V 1
F
RX
Supported received frequency. — 100 kHz -
Y
dc
Y output duty cycle. 40 60 % 2
Y
tiPDr
Receiver propagation delay rise. — 400 ns 1, 2, 4
Y
tiPDf
Receiver propagation delay fall. — 20 ns 1, 2, 4
1. Measured with an edge rate of 1 µs at the PAD pin.
2. Assuming perfect duty cycle on input.
3. Measured at the maximum operating frequency.
4. Typical simulation corner only.
