AMERITECH AM8a - Table 7-7. RS232 On-Off (Control Toggle) Commands; Table 7-8. RS232 Call Initiate (Signaling) Commands

AM8a Instruction Manual (18-0037) RS232 Entries and Printouts
0037-S07.L_58 February 10, 2000
7-13
Table 7-7. RS232 On-Off (Control Toggle) Commands
COMMAND DEFINITION
(IP+)
(IP-)
INPUT (on)
INPUT (off)
(TI+)
TI#)
(TI-)
TIMS (on): T/R -> TX/2W
TX/2W -> TX/2W
TIMS (on): R/X -> RX
PCM -> TIMS
Selected Chan RX RX
TX TX
TIMS (rev) PCM -> TIMS
Selected Chan RX RX
monitor only TX TX
TIMS (off)
(TK+)
(TK-)
TALK (Speakerphone on)
TALK (Speakerphone off)
(AU+)
(AU-)
AUTO (Auto call/answer on)
AUTO (Auto call/answer off)
Table 7-8. RS232 Call Initiate (Signaling) Commands
COMMAND DEFINITION
(SZ+)
(SZ-)
SEIZE (line on)
SEIZE (line off)
(RI+)
(RI-)
RING (supply ring)
RING (remove ring)
(TN+)
(TN-)
SEND TONE (TONE on)
SEND TONE (TONE off)
(ST+)
(ST-)
START (Initiate signal)
START (Remove signal)
(RV+)
(RV-)
REV (Reverse polarity)
REV (Normal polarity)
