AMERITECH AM8a - Figure 7-6. Manual Long Print (Meter Display Example)

RS232 Entries and Printouts (18-0037) AM8a Instruction Manual
February 10, 2000 0037-S07.L_
7-20
(PMO) RS232 command equivalent
Meter Display:
MEASURE SCALE MEASURE SCALE
Vt-r dc 100 Vr-g dc 150
Vt-r dc = 47.6 ..........""""".....
Vr-g dc = -47.2 ......."""..........
PCM1:BPV FERR CRC SLIPS YELLOW BLUE
CNT 0 0 0 0 0 0
PCM1: BLUE YELLOW
STATUS: NO NO
PCM2:BPV FERR CRC SLIPS YELLOW BLUE
0 0 0 0 0 0
PCM2: BLUE YELLOW
STATUS: NO NO
PCM TX FRAME SYNC: .......!........(use CANCEL or "(CN)" command to align !)
PCM RX FRAME SYNC: .......!........
NOISE ---- dBrn ....................
INPUT TX FILTER CMSG
bit indicators
TX A-B_ ..._=. =..-._ ._.=._ =._._. - : a on, b off
RX A-B_ ..=._- .....- =..... .-.-=. = : both on
_ : b on, a off
. : both off
ALARM TX -A--A AAA-A -A---
ALARM RX -A AA--A --AA-
PROTECTION TX 0100
PROTECTION RX 0000
MAINTENANCE TX 000 CHAN= 13 TS= 02
MAINTENANCE RX 010 CHAN= 37 TS= 02
Figure 7-6. Manual Long Print (Meter Display Example)
Figure 7-7 shows a sample of a Long Print for SETUP. This printout is for a unit in
Monitor mode which is why "No emulation setup for Monitor type" appears in the
printout.
When in the Emulate mode, "Analyze setup", and "Speed/auto dial setup" lists will
contain the same parameters for all configurations. The "Configuration setup" and
"Emulate setup" lists will contain the parameters that are appropriate to MODE: IMITATE
(te/line or switch), CIRCUIT:ANALOG/PCM, or TRUNK: TRUNK TYPE parameter settings.
