AMERITECH AM8a - Table 7-12. RS232 Meter Display Commands (PCM Measurements)

AM8a Instruction Manual (18-0037) RS232 Entries and Printouts
0037-S07.L_58 February 10, 2000
7-15
= 10
= 11
= 12
= 13
= 14
à
à
à
à
à
RX Tone
TX Vt-r ac
TX Vcm ac
RX Vt-r ac
RX Vcm ac
RX Tone
TX Vt-r ac
TX Vcm ac
RX Vt-r ac
RX Vcm ac
TX1 Vcm ac
RX1 Vcm ac
TX2 Vcm ac
RX2 Vcm ac
= 15
= 16
= 17
= 18
à
à
à
à
Ve ac
Vsg ac
Vm ac
Vsb ac
Table 7-12. RS232 Meter Display Commands (PCM Measurements)
COMMAND DEFINITION
(MP1) Select PCM1 and display Bipolar Violation measurements. Typical:
PCM1: BPV FERR CRC SLIPS YELLOW BLUE
CNT 0 0 0 0 0 0
(MP3) Select PCM1 and display Alarm Status. Typical:
PCM1: BLUE YELLOW
STATUS: NO YES
(MP2) Select PCM2 and display Bipolar Violation measurements. Typical:
PCM2: BPV FERR CRC SLIPS YELLOW BLUE
CNT 0 0 0 0 0 0
(MP4) Select PCM1 and display Alarm Status. Typical:
PCM2: BLUE YELLOW
STATUS: YES NO
(MPH) Display Frame Sync Measurement for PCM1 or PCM2. Typical:
PCM TX FRAME SYNC: . . . . . . . . | . . . . . . . . . . .
PCM RX FRAME SYNC: . . . . . . . . . . . . . | . . . . . .
(MAB) Display PCM TX and RX a/b Bits (Monitor Mode only)
TX A-B_ . . . _ = . = . . - . _ . _ . = . _ = . _ . _ .
RX A-B_ . . = . - . . . . . - = . . . . . . - . - = .
Bit Indicators: - a on, b off _ b on, a off . both off = both on
(MAM) Display SLC®96 Alarm Message Status. Typical:
ALARM TX: - - -AA A- - - - - - - - -
ALARM RX: - - AA- - - - - - - -
(MPT) Display SLC®96 Protection Message Status. Typical:
PROTECTION TX: 1111
PROTECTION RX: 1110
(MMT) Display SLC®96 Maintenance Message Status. Typical:
MAINTENANCE TX: 000 CHNL= 00 TS= 00
MAINTENANCE RX: 111 CHNL= 00 TS= 00
