RS232 Entries and Printouts (18-0037) AM8a Instruction Manual
February 10, 2000 0037-S07.L_
7-18
(PEB) RS232 Command Equivalent
EVENTS & DETAILS
> 16:32:15 08-16-91 Emulate
R 00:00:00 Ring Begin 100.0v 20.0 hz`
r 00:01.924 Ring End
R 00:06:003 Ring Begin 080.00v 20.0 hz
r 00:07.928 Ring End
R 00:12:006 Ring Begin 081.00 20.0 hz
r 00:13.932 Ring End
Figure 7-3. Events & Details Printout (Emulate Mode)
7.2.6 Manual Short Print: To request a Short Print, press [SHIFT] then [PRINT] and data
appropriate to what has been selected for display is printed. Figure 7-1 shows a short
print in EVENTS DISPLAY, Figure 7-4 shows a METER DISPLAY (when first display has
been selected), Figure 7-5 shows a SETUP DISPLAY for EMULATE parameters.
NOTE: The RS232 commands in "()" and the three columns to the right side are
not in the printout. They are cross-reference aids. Only the lines
appropriate to the configuration (indicated by *) are printed.
MEASURE SCALE MEASURE SCALE
Vt-r dc 100 Vr-g dc 150
Figure 7-4. Manual Short Print (Meter Display Example)
