RS232 Entries and Printouts (18-0037) AM8a Instruction Manual
February 10, 2000 0037-S07.L_
7-16
Table 7-13. RS232 Meter Display Commands (Noise Measurements)
COMMAND DEFINITION
(MN0) or
(MN1)
Select Noise measurement display
NOISE -65 dBrn | | | | | | | . . . . . . . . . . . . .
INPUT TX FILTER CMSG
(MN0) (MN0 = 00) for Select Noise measurement INPUT TX.
(MN0 = 01) for Select Noise measurement INPUT RX.
(MN1) (MN1 = 00) for Select Noise measurement FILTER CMSG.
(MN1 = 01) for Select Noise measurement FILTER FLAT.
7.2 PRINTOUTS
A variety of printouts are available from the AM8a. The printouts may be manual or
automatic. The MANUAL printouts are controlled by the PRINT key on the front panel or the
RS232 Printing Commands shown in Table 7-2.
The automatic printing selections are provided in the PRINT CONFIG menu AUTOPRINT
parameter. (Refer to 2.7 for description of this menu). The following sub-sections provide
information on the print formats.
NOTE: Automatic printouts begin at the end of the start of the next call sequence.
7.2.1 off: No automatic printout will occur. Operator may use the [SHIFT] and [PRINT] keys
for short or long print, or can use equivalent RS232 commands (PET) or (PEB) when
printouts are required.
7.2.2 all calls,events only: The EVENT only printout will show the first line of the Events
Display. This printout can have the same maximum length as the Events Display (80
characters). Figure 7-1 is a sample of an EVENT only printout. (This is also the
printout that would result from a manual short printout while in EVENTS DISPLAY
mode.)
>HX1x2765432654325h
Figure 7-1. Event-only Printout
NOTE: Any underlined characters indicate the Event originated from the switch.
Refer to Section 1 for the explanation of the event codes.
