AMERITECH AM8a - Table 7-9. RS232 Events Display Commands; Table 7-10. RS232 Meter Display Commands (Analog Voltage Measurements); Table 7-11. RS232 Meter Display Commands (Meter Selections)

RS232 Entries and Printouts (18-0037) AM8a Instruction Manual
February 10, 2000 0037-S07.L_
7-14
Table 7-9. RS232 Events Display Commands
COMMAND DEFINITION
(Vn) EVENTS display including detailed event n (n = 0 to 79).
(VR) EVENTS display and move cursor right.
(VL) EVENTS display and move cursor left.
(VF) FREEZE events.
(CN) CANCEL (EVENT FREEZE or abort selection).
Table 7-10. RS232 Meter Display Commands (Analog Voltage Measurements)
COMMAND DEFINITION
(MV0)
(MV1)
(MV2)
(MV3)
Display MEASURE/SCALE for Meter 1 and Meter 2. Typical:
MEASURE SCALE MEASURE SCALE
Vt-r dc 100 Vr-g dc 5
Meter 1 Meter 2
(MV0=x) Meter 1 MEASURE select. See Table 7-11 for the value of x.
(MV1=n) Meter 1 SCALE entry for MVV bar graph. n = .1 through 300.
(MV2=x) Meter 2 MEASURE select. See Table 7-11 for the value of x.
(MV3=n) Meter 2 SCALE entry for MVV bar graph. n = .1 through 300.
(MVV) Meter 1 and Meter 2 analog and bar graph display. Typical:
t-r dc = 42.6 . . . . . . . . . . . . . | | | | | . . . . . Meter 1
r-g dc = 0.2 . . . . . . . . . . . . . . . . . . . . . . . Meter 2
Table 7-11. RS232 Meter Display Commands (Meter Selections)
(MV0=x)
(MV2=x)
x value
LOOP START
GROUND START
D.I.D
E&M 2W
E&M 4W
SF PCM 1
PCM 2
= 00
= 01
= 02
= 03
= 04
Vt-r dc
Vcm dc
Vt-g dc
Vr-g dc
It(ma) dc
à
TX Vt-r dc
TX Vcm dc
RX Vt-r dc
RX Vcm dc
à
TX Vt-r dc
TX Vcm dc
RX Vt-r dc
RX Vcm dc
TX1 Vcm dc
RX1 dBsx
RX1 Vcm dc
TX2 Vcm dc
RX2 dBsx
= 05
= 06
= 07
= 08
= 09
Tone
Vt-r ac
Vcm ac
Vt-g ac
Vr-g ac
Ve dc
Vsg dc
Vsb dc
Vm
TX Tone
à
à
à
à
TX Tone
RX2 Vcm dc
TX1 Tone
RX1 Tone
TX1 Tone
RX1 Tone
