Configuration Parameters (18-0037) AM8a Instruction Manual
February 10, 2000 0037-S02.L_
2-12
2.9 CLOCK CONFIG
This menu is used to set the Real Time Clock and Date which appears in the Events Display
as well as on reports generated via the RS232 port. These parameters can only be changed by
operator input. The factory default clock setting is shown below ("X"s are not part of
display):
CLOCK :
CONFIG:
DATE(MM/DD/YY)
XXX1 XXX1 XX91
1-12 1-31 0-99
TIME(HH/MM)
XX12 XXX1
0-23 0-59
Alternate:
NOTE: As entries into date and time fields are made, leading zeroes (0) are displayed
where "X"s are shown. Leading 0s are cleared when the next field is selected.
This is typical of most displays which require entry of numeric data.
2.10 AM8a CONFIG
The VERSION menu contains information only. It is not programmable. The CPU field shows
the firmware version used for the main control of the AM8a. The DSP0 and DSP1 fields
indicate the DSP firmware used for audio processing functions such as tone generation and
measurements. The display below is to illustrate format; the actual numbers displayed may be
different.
AM8a :
CONFIG:
CPU
105
DSP0
100
DSP1
100
