AMERITECH AM8a - Send Tone Emulate; Dial Tone Emulate 2

Emulation Parameters (18-0037) AM8a Instruction Manual
February 10, 2000 0037-S03.L_
3-4
3.7 SEND TONE EMULATE
This menu allows the user to program the level and frequency of a single test tone which may
be sent from the AM8a when the SEND TONE key is pressed.
SEND TONE:
EMULATE :
LEVELdBm
-10
-40 to 0 (1dB steps)
FREQUENCYhz
1004
300 to 3300 (1hz steps)Alternate:
3.7.1 LEVELdBm: This controls the level of the single test tone.
3.7.2 FREQUENCYhz: This controls the frequency of the single test tone.
3.8 DIAL TONE EMULATE 1
This parameter allows a Dial Tone Cadence to be programmed. If all the OFF times are set for
0000, and only one ON time is set to 9999, a continuous Dial Tone will be sent if Dial Tone is
selected as the START SIGNAL.
DIAL TONE:
EMULATE 1:
ON/OFFms
9999 0
ON/OFFms
0 0
ON/OFFms
0 0
Alternate:
0 to 9999 (1ms steps)
Programming an OFF time will provide interrupted dial tone. The additional ON/OFF
parameters will only be used if the first OFF time is given a value greater than zero. Use of
these parameters will provide a dial-tone cadence like "one long, two short".
3.9 DIAL TONE EMULATE 2
The Dial Tone provided by the AM8a when seized by the Calling Party (and DIALING: START
SIGNAL is set to dial tone) may be programmed here. The dial tone consists of two tones
generated simultaneously. The LEVEL and FREQuency of each tone can be varied
independently.
