AMERITECH AM8a - Table 7-5. RS232 ANALYZE Menu Commands

RS232 Entries and Printouts (18-0037) AM8a Instruction Manual
February 10, 2000 0037-S07.L_
7-10
(EDB) DIAL TONE: T1:/Hz. (EDB) = 0;300 to <350> to 3300 (Dial Tone 1 Frequency).
3.9.1 (2)
(EDC) DIAL TONE: T2:dBm. (EDC) = -40 to <-13> to –3 (Dial Tone 2 Level). 3.9.2 (2)
(EDD) DIAL TONE: /FREQ. (EDB) = 15 to <250> to 9999 Hz (seizure-to-dial tone delay).
3.9.2 (2)
(EDT) DIAL TONE: DL SNDms. (EDT) = 0;300 to <440> to 3300 Hz (Dial Tone 2
Frequency). 3.9.3 (2)
(EFS) RECALL: HOOKFLASHms. (EFS) = 15 to <500> to 999. 3.10.1
(EUB) RECALL: LINE UNBALms. (EUB) = 15 to <500> to 9999 msec. 3.10.2
(ER1) RINGING: ON. (ER1) = 0 to <2000> to 5000msec (Ring 1 ON-Time) 3.11.1 (1)
(ER2) RINGING: /OFFms (ER2) = 0 to <4000> to 9999msec (Ring 1 OFF-Time) 3.11.1
(1)
(ER3) RINGING: …ON… . (ER3) = <0> to 5000msec (Ring 2 ON-Time) 3.11.2 (1)
(ER4) RINGING: …/OFFms (ER4) = <0> to 9999msec (Ring 2 OFF-Time) 3.11.2 (1)
(ER5) RINGING: …ON. (ER5) = <0> to 5000msec (Ring 3 ON-Time) 3.11.2 (1)
(ER6) RINGING: … …/OFFms (ER6) = <0> to 9999msec (Ring 3 OFF-Time) 3.11.2 (1)
(ERV) RINGING: VOLTAGEvrms. (ERV) = 30 to <85> to 105 3.12.1 (2)
(ERF) RINGING: FREQUENCYhz. (ERF) = 15.0 to <20.0> to 70.0 3.12.2 (2)
(ELB) START TIME: DLY BGN. (ELB) = 15 to <50> to 999 3.13.1
(ELE) START TIME: DLY/ENDms. (ELE) = 100 to <250> to 9999msec 3.13.1
(EWB) START TIME: WINK: BGN. (EWB) = 15 to <50> to 999 3.13.2
(EWD) START TIME: WINK:/DURms. (EWD) = 50 to <250> to 999msec 3.13.2
(ESL) SF: LEVELdBm. (ESL) = -40 to <-10> to 0 dBm. 3.14.1
(ESF) SF: FREQ+%hz. (ESF) = -2.0 to <0.0> to 2.0% 3.14.2
Table 7-5. RS232 ANALYZE Menu Commands
COMMAND DEFINITION
(R20) – (R39) RECALL EMULATE/ANALYZE SETUPs from location ID 20 through ID 39.
[SHIFT] + [RECALL] + [location ID] keys.
(R40) RECALL all SETUPs from last power down. [SHIFT] + [RECALL] + [*] keys.
(Z20) – (Z39) STORE EMULATE/ANALYZE SETUPs from location ID 20 through ID 39. [SHIFT]
+ [STORE] + [location ID] keys.
(AHF) HOOK: FLASHms(min) (AHF) = 50 to <450> (Min.) to 1250 4.1.1
(AHD) HOOK: DISCONNECTms(min) (AHD) = 50 to <1000> (Min.) to 1250 4.1.2
(AWD) STRT SIG: EXPECTED TYPE. (AWD = 00) for <dialtone/wink>, (AWD = 01) for
dialtone/delay. 4.2.1, 4.2.2
