Table 7-4. RS232 EMULATE Menu Commands
COMMAND DEFINITION
(R20) – (R39) RECALL EMULATE/ANALYZE SETUPs from location ID 20 through ID 39.
[SHIFT] + [RECALL] + [location ID] keys.
(R40) RECALL all SETUPs from last power down. [SHIFT] + [RECALL] + [*] keys.
(Z20) – (Z39) STORE EMULATE/ANALYZE SETUPs from location ID 20 through ID 39. [SHIFT]
+ [STORE] + [location ID] keys.
(ELV) LOOP: VOLTAGEvdc. (ELV = 20) for 20 to <48> to (ELV = 72) for 72 volts. 3.1.1
(ELL) LOOP: LENGTH ohm. (ELL) = 0, 300, 600, 900, <1200>, 1500, 1800, or 2100.
3.1.2
(EIC) TERMINATION: 2.16uf. (EIC = 00) for <in>, (EIC = 01) for out. 3.2.1
(EDH) TERMINATION: DC HOLD. (EDH) = 10ohm, <330ohm>, or 430ohm. 3.2.2
(ELT) DIALING: LOOP TYPE. (ELT = 00) for <pulse>, (ELT = 01) for dtmf, (ELT = 02) for
mf(R1). 3.3.1
(ESS) DIALING: START SIGNAL. (ESS = 00) for immediate, (ESS = 01) for <wink>,
(ESS = 02) for delay, (ESS= 03) for dial tone. 3.3.2
(EPS) PULSE: SPEEDpps. (EPS) = 5 to <10> to 25. 3.4.1
(EPB) PULSE: BREAK%. (EPB) = 40 to <60> to 85. 3.4.2
(EPI) PULSE: INTRDIGITms. (EPI) = 120 to <600> to 999. 3.4.3
(ET1) DTMF/MF: HI: dBm. (ET1) = -40 to <-7> to -3. 3.5.1 (1)
(ET2) DTMF/MF: HI/hz%. (ET2) = -5.0 to <0.0> to +5. 3.5.1 (1)
(ET3) DTMF/MF: LO: dBm. (ET3) = -40 to <-7> to -3. 3.5.2 (1)
(ET4) DTMF/MF: LO/hz%. (ET4) = -5.0 to <0.0> to +5. 3.5.2 (1)
(EEN) DTMF/MF: ON. (EEN) = -25 to <50> to 99. 3.6.1 (2)
(EEF) DTMF/MF: OFFms. (EEF) = -25 to <50> to 99msec. 3.6.1 (2)
(EHL) SEND TONE: LEVELdBm. (EHL) = -40 to <-10> to 0. 3.7.1
(EHF) SEND TONE: FREQUENCYhz. (EHF) = 300 to <1004> to 3300. 3.7.2
(ED1) DIAL TONE: ON. (ED1) = 0 to <9999>msec (Dial Tone 1 ON-Time). 3.8 (1)
(ED2) DIAL TONE: OFFms. (ED2) = <0> to 9999 msec (Dial Tone 1 OFF-Time). 3.8 (1)
(ED3) DIAL TONE: …ON… . (ED3) = <0> to 9999 msec (Dial Tone 2 ON-Time). 3.8 (1)
(ED4) DIAL TONE: … /OFFms. (ED4) = <0> to 9999 msec (Dial Tone 2 OFF-Time). 3.8
(1)
(ED5) DIAL TONE: …ON. (ED5) = <0> to 9999 msec (Dial Tone 3 ON-Time). 3.8 (1)
(ED6) DIAL TONE: … …/OFFms. (ED6) = <0> to 9999 msec (Dial Tone 3 OFF-Time).
3.8 (1)
(EDA) DIAL TONE: T1:dBm. (EDA) = -40 to <-13> to –3 (Dial Tone 1 Level). 3.9.1 (2)
