RS232 Entries and Printouts (18-0037) AM8a Instruction Manual
February 10, 2000 0037-S07.L_
7-6
(PAO) Print Analyze Only: This command prints all analyze parameters. It is equivalent to
pressing [SHIFT] then [PRINT] briefly (short print) while the SETUP AUTO DIAL
function is activated.
(PSO) Print Speed/Auto Dial Only: This command prints current auto-dial number. It is
equivalent to pressing [SHIFT] then [PRINT] briefly (short print) while the SETUP
ANALYZE function is activated.
(PAL) Print All SETUP: This command prints all parameters that are appropriate to the
configuration and operating mode. It is equivalent to pressing [SHIFT] then [PRINT]
for two seconds (long print) while any of the SETUP functions are activated.
(POM=nn) Print One Memory (where nn = 0-19 for Configure parameters, nn = 20-39 for Emulate
and Analyze parameters, or nn = 40 for all Power Off Recall parameters. This
command could be issued after doing a store command (Znn). This command is not
the same as doing a recall (Rnn) followed by a (PAL), since operating parameters are
not changed.
Table 7-3. RS232 CONFIGuration Menu Commands
COMMAND DEFINITION
(R0) – (R19) RECALL CONFIG’N SETUPs from location ID 0 through ID 19. [SHIFT] + [RECALL]
+ [location ID] keys.
(R40) RECALL all SETUPs from last power down. [SHIFT] + [RECALL] + [*] keys.
(Z0) – (Z19) STORE CONFIG’N SETUPs from location ID 0 through ID 19. [SHIFT] + [STORE] +
[location ID] keys.
(CTD) MODE: IMITATE. (CTD = 00) for te/line. (CTD = 01) for <switch>. 2.1.1
(CEM) MODE: MODE. (CEM = 00) for emulate. (CEM = 01) for <monitor>. 2.1.2
(CIR) CIRCUIT: ANALOG IMPEDANCE. (CIR) = 135, 600, <900>, or 1200. 2.2.1
(CTA) CIRCUIT: ANALOG/PCM. (CTA = 00) for analog, (CTA = 01) for pcm int clk, (CTA =
02) for <pcm loop clk>. 2.2.2
(CTC) PCM: INPUT. (CTC = 00) for <pcm1 on>, (CTC = 01) for pcm2 on, (CTC = 02) for
rpt1 to 2, (CTC = 03) for rpt2 to 1. 2.3.1 (1)
(CFM) PCM: FRAMING. (CFM = 00) for <D3/D4>, (CFM = 01) for ESF, (CFM = 02) for
SLC®96 I, (CFM = 03) for SLC®96 II. 2.3.2 (1)
(CZS) PCM: ZEROSUP. (CZS = 00) for B8ZS, (CZS = 01) for ZCS, (CZS = 02) for <AMI>.
2.3.3 (1)
(CTH) PCM: CHAN. (CTH = 00) for Channel <0> (random), (CTH = 24) to Channel 24,
(CTH = -97) for SLC® Data link monitor, (CTH = -1) for SLC® Channel 1, (CTH = -
96) to Channel 96. 2.3.4 (1)
(CS1) PCM: OFF HK a/b. (CS1 = 00) for <auto>, (CS1 = 01) for 0/0, (CS1 = 02) for 0/1,
(CS1 = 03) for 1/0, (CS1 = 04) for 1/1, (CS1 = 05) for 0/X, (CS1 = 06) for 1/X, (CS1 =
07) for X/0, (CS1 = 08) for X/1, (CS1 = 09) for. 2.3.5 (2)
