AM8a Instruction Manual (18-0037) RS232 Entries and Printouts
0037-S07.L_58 February 10, 2000
7-17
7.2.3 all calls,events & details: The EVENTS & DETAILS printout will provide the Event from
the first line of the Events Display, then the second line Analysis. This is repeated for
each event. Figure 7-2 is a sample of an EVENTS & DETAILS Monitor mode printout
(not based on EVENT printout described in the preceding sub-section). Figure 7-3 is a
sample for ring details. (These printouts are also typical of Manual long print from the
unit while in EVENTS DISPLAY mode.)
7.2.4 flawed calls,events only: Printout format is the same as shown in Figure 7-1. However,
only those calls outside tolerance specified in the ANALYZE setup menus will be output,
and an "*" at the end of the line will indicate the flawed call. Events which cannot be
recognized will be indicated with a "?".
7.2.5 flawed calls, events & details: Printout format is the same as shown in Figures 7-2 or
7-3. An "*" will be shown following those events which are outside of tolerance.
> 02:23:18 12-28-92 Monitor Term/Line
H 00:00:00 Off Hook
X 00:00.194 Dial Tone Begin
1 00:01.483 T1 -06/697 -06/1209 1483/0051
x 00:01.586 DT End -10/439 -10/350
2 00:01.584 T2 -06/698 -07/1336 0050/0051
3 00:01.685 T3 -07/697 -06/1477 0050/0050
4 00:01.785 T4 -06/770 -06/1209 0049/0051
5 00:01.885 T5 -06/770 -06/1336 0050/0050
6 00:01.985 T6 -07/770 -06/1477 0051/0049
7 00:02.085 T7 -06/853 -06/1209 0050/0051
8 00:02.186 T8 -07/852 -06/1336 0050/0050
9 00:02.286 T9 -06/851 -07/1477 0049/0052
0 00:02.387 T0 -07/942 -06/1336 0050/0050
P 00:03.560 Supervision Begin
T 00:05.570 Tone Begin
t 00:05.798 Tone End -10 dBm 0697 hz
h 00:05.720 On Hook
p 00:06.245 Supervision End
Event Details
Elapsed Time Reletive to Off Hook
Events generated from the switch
Events generated from the Term/Line
Figure 7-2. Events & Details Printout (Monitor Mode)
