Configuration Parameters (18-0037) AM8a Instruction Manual
February 10, 2000 0037-S02.L_
2-4
rpt 2 to 1: is used during Drop & Insert testing. This mode will allow the selected
CHANnel to be used for emulation towards the equipment connected to the PCM2 input
jacks; other channels are uninterrupted to PCM1.
NOTE: In MONITOR mode all channels pass from PCM1 to PCM2 when rpt 1 to 2 or
rpt 2 to 1 are selected. See Section 6 for metering the a and b bits to find an
idle channel that can be selected for drop and insert testing.
In Drop & Insert testing, the equipment which supplies the "Master" clock
for framing must be connected to the PCM1 input jack.
2.3.2 FRAMING: This parameter selects the span framing type assignment that the AM8a can
emulate and monitor.
D3/D4: is the most popular type of framing. It uses 12 separate frames in a super-
frame. The signaling bits are identified as "a" and "b" bits.
ESF: Extended SuperFrame is another popular type of framing. This type uses 24
frames rather than 12 frames. Its signaling bits are" a, b, c, and d".
SLC®96 I: (SLC® 96 Mode I) monitors 96 channels or data link on four spans (A, B, C,
and D). Assignment of channels to time-slots is fixed. Refer to Table 6-5 for these
assignments.
SLC®96 II: (SLC®96 Mode II) monitors 96 channels or data link on two spans (A and C).
Assignment of channels to time-slots is on as-available basis. Refer to 2.5.4 for use of
activity message to determine line groups and active channels.
NOTE: SLC®96 I and SLC®96 II can only be used in monitor mode.
2.3.3 ZERO SUP: Zero Suppression is the way that the AM8a handles a data pattern of all
"0's" during transmission.
AMI: (Alternate Mark Inversion) is the standard protocol for T1 spans. AMI does not
supply any zero suppression conversions.
B8ZS: (Binary Eight Zero Suppression) will insert two bipolar violations when eight
consecutive zeros are encountered. The receiving equipment will recognize this and
remove the BPV's and correctly interpret the data.
