Ametek OCS 500N6 Series User Manual

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 17 / 80
3.2.
Menu structure
Page 0...4
Page 0
Page 1
Page 2
Page 3
Page 4..x
MAIN MENU
F1 Damped Osc. 100kHz IEC 61000-4-18
F2 Damped Osc. 1MHz IEC 61000-4-18
F3 Ringwave 100kHz IEC 61000-4-12
F4 Damped Osc. 100kHz MF IEC 61000-4-10
F5 Damped Osc. 1MHz MF IEC 61000-4-10
F6 Damped Osc. 1MHz ext. IEC 60255-26
F7 Service
Damp. Osc.100kHz IEC 61000-4-18
F1 Quick Start
F2 Standard test routines
F3 User test routines
Quick Start
F1 Start
F2 Change
F3 Continue
Start
Start the test routine
Change
Select all parameters
Continue
Continue the test routine
Damped Osc. 1MHz IEC 61000-4-18
F1 Quick Start
F2 Standard test routines
F3 User test routines
Standard test routines
Preprogrammed test routines as
per standard requirements
Standard routines
F1 Common Mode
F2 Differential Mode
Standard routines
F1 Level 1
F2 Level 2
F3 Level 3
F7 Manual
Ringwave IEC 61000-4-12
F1 Quick Start
F2 Standard test routines
F3 User test routines
User test routines
Preprogrammed test routines for
evaluation and design support
User test routines
F1 Synchronous to the mains
F2 Random burst release
F3 Change V after T by U
F4 Change polarity after T
User test routines
F1 Start
F2 Change
F3 Continue
Damped Osc. 100Hz MF IEC 61000-4-10
F1 Quick Start
F2 Standard routines
F3 User test routines
F7 Magnetic field correction factor
Setup Magnetic field
F1 Coil factor Cf [1/m]
Magnetic field factors
Correction factors for magnetic field
antenna
Damped Osc. 1MHz IEC 60255-26
F1 Quick Start
F2 Standard test routines
F3 User test routines
Damped Osc. 1MHz IEC 60255-26
Standard test routines
F1 Common Mode 1
F2 Common Mode 2
F3 Differential Mode
Damped Osc. 1MHz IEC 60255-26
User test routines
F1 Synchronous to the mains
F2 Random burst release
F3 Change V after T by U
F4 Change polarity after T
Damped Osc. 1MHz IEC 60...
F1 Level 1
F2 Level 2
Damped Osc. 1MHz Ext IEC 60255-
26
F1 Quick Start
F2 Standard test routines
F3 User test routines
Setup
F1 Change language
F2 LCD backlighting
F3 Interfaces
F4 Beeper
F5 Power –on counter
Change language
German or English
LCD backlighting
On, Off or Auto
Interfaces Select all parameters
Beeper (on, off)
Power.on counter Display of
Power on time and Testing time
Service
F1 Addresses
F2 Setup
F3 Change standard levels
F7 Status
Change standard level
F1 set all parameters acc.to
standard
F2 Damped Osc. 100kHz
F3 Damped Osc. 1MHz
F4 Ringwave 100kHz
F5 Damped Osc. 1MHz MF
Change standard level
F1 Level 1
F2 Level 2
F3 Level 3
F4 Level 4
F6 Coupling Diff / Common
mode
