AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 52 / 80
Standard test Routine
Page 3
With the selection of F1 ....F4 the test is conducted
automatically with the parameters and the test sequence
as required per IEC 61000-4-12. The only parameters
the operator is able to change are the
- impedance
- repetition rate
- number of pulses per test level
- trigger Auto / Manual
Level test
A selected level will step through all couplings in the selected Mode. The following parameters are used:
each coupling positive and negative
Differential Mode L-N
Common Mode L-PE, N-PE, L+N-PE
Ringwave IEC 61000-4-12 Level 3
Ringwave IEC 61000-4-12 Level 3
V = -980 V act coupling 4
STOP Step I = - 85.A complete 29
- The counter shows the number of triggered pulses per actual coupling as well as the number of all triggered test
pulses within the running test sequence.
- Pushing the function key F2 STEP will bring you into the next iteration sequence.
