Damped Oscillatory Magnetic Field as per IEC 61000-4-10
For magnetic test a separate manual is damped oscillating magnetic field.
For the magnetic field test, an additional and more detailed operating manual is available. This manual can be
requested if required, or is included in case of an upgrade.
9.1.
General
Damped oscillatory magnetic fields are generated by switching of H.V. circuit breakers or disconnectors.
The test is mainly applicable to electronic equipment to be installed in H.V. sub-stations. Power plants,
switchgear installations, smart grid systems may also be applicable to this standard and may be considered by
Product Committees.
Testlevel
Peak current I ± 20 % [A]
System using 1 m x 1 m
standard induction coil
System using 1 m x 2,6 m
standard induction coil
1
2
3
4
5
X
not applicable
not applicable
11.1
33.3
111
Special/0,9
not applicable
not applicable
15.2
45.5
see note 2
Special/0,66
NOTE 1 – The values 0,9 and 0,66 are the calculated coil factors of standard induction
coils.
NOTE 2 – The calculated value is 152; however, there is currently no commercial generator
available.
Table 2 – Peak current specifications of the test system as per. Draft IEC 61000-4-10 Ed. 2.0
Calibration items
Oscillation frequency
100 kHz
1 MHz
Oscillation period
T = 10 μs ± 10 %
T = 1 μs ± 10 %
Repetition rate of the pulses
Trep = 25 ms ± 10 %
Trep = 2,5 ms ± 10 %
Decay rate of one pulse
Table 3 – Waveform specifications of the test system as per. Draft IEC 61000-4-10 Ed. 2.0
