1.3.
Standards covered by OCS 500N6 / N6F generators
Fully equipped OCS 500N6 / N6F generators cover the following standards
- IEC 61000-4-10
Oscillatory Magnetic Field test
- IEC 61000-4-12
- ANSI-IEEE C62.41.2
- ANSI-IEEE C62.45
Ring wave immunity test
- IEC 61000-4-18
Oscillatory waves immunity test
Slow damped oscillatory wave (100 kHz or 1 MHz)
Fast damped oscillatory wave (3, 10, 30 MHz) OCS500N6F only
- IEC 60255-26
Measuring relays and protection equipment
- 1 MHz burst immunity tests
1.4.
Models and options
This manual is for the written for the following device model and options:
Device:
Unit for damped waves as per IEC 61000-4-12 / -18 and ANSI C62-41:
- incl. damped oscillatory waves 100 kHz and 1 MHz
- incl. Ring Wave 100 kHz
Model
name till 2008
coupling network
AC voltage
DC voltage
OCS 500 N6
OCS 500 M6
1-phase
250 V / 16 A
250 V / 10 A
OCS 500 N6.2
OCS 500 M6S2
1-phase
250 V / 32 A
250 V / 20 A
OCS 500 N6.3
OCS 500 M6S3
3-phases
3x400 V / 16 A
250 V / 10 A
OCS 500 N6.4
OCS 500 M6S4
3-phases
3x400 V / 32 A
250 V / 20 A
OCS 500 M6S5
3-phases
3x400 V /100 A
250 V / 20 A
OCS 500 M6-690V
1-phase
690 V / 32 A
250 V / 20 A
OCS 500 M6S8
3-phases
3x440 V /100 A
250 V / 20 A
OCS500 N6.11
3-phases
3x690 V /32 A
250 V / 32 A
OCS500N6F
1-phases
250 V / 16 A
250 V / 16 A
OCS500N6F.1
1-phases
250 V / 32 A
250 V / 32 A
OCS500N6F.2
3-phases
3x440 V / 16 A
250 V / 16 A
OCS500N6F.3
3-phases
3x440 V / 32 A
250 V / 32 A
OCS500N6F.4
See special model
3-phases
3x440 V / 32 A
250 V / 32 A
Model for 3kV on direct HV output
coupling network
AC voltage
DC voltage
OCS500N6.5
CDN1-16 A
250 V / 16 A
250 V / 16 A
OCS500N6.6
CDN1-32 A
250 V / 32 A
250 V / 32 A
OCS500N6.7
CDN3-16 A
3x440 V / 16 A
250 V / 16 A
OCS500N6.8
CDN3-32 A
3x440 V / 32 A
250 V / 32 A
OCS500M6S8
