AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 21 / 80
3.6.
Service
SERVICE
F1 : Addresses
F2 : Setup
F3 : Change standard levels
F7 : Status
F1
F2
F3
F4
F5
F6
F7
F1 Addresses
The addresses of the AMETEK CTS GmbH in
Switzerland and Germany are shown. The addresses
of all AMETEK CTS sales agencies are listed on the
web site of EM TEST under :
www.emtest.com
F2 Set-up
The software will clearly explain the set-up procedure.
F3 Change standard levels OCS 500 N6.x
The stored standard test levels can be changed within this menu.
F1: Reset all standard levels
F2: Change standard level for IEC 61000-4-18 Damped Oscillatory 100 kHz
F3: Change standard level for IEC 61000-4-18 Damped Oscillatory 1MHz
F4: Change standard level for IEC 61000-4-12 Ringwave 100 kHz
F5: Change standard level for IEC 61000-4-10 100 kHz Damped Oscillatory Magnetic Field
F6: Change standard level for IEC 61000-4-10 1 MHz Damped Oscillatory Magnetic Field
F7: Change standard level for IEC 60255-26 Damped Oscillatory 1MHz ext.
F3 Change standard levels OCS 500 N6F.x
The stored standard test levels can be changed within this menu.
F1 Fast Damped Osc. IEC 61000-4-18
F1: Set all standard acc. to standard
F2: Damped Osc. 3MHz IEC 61000-4-18 Damped Oscillatory 3MHz
F3: Damped Osc. 10MHz IEC 61000-4-18 Damped Oscillatory 10MHz
F4: Damped Osc. 30MHz IEC 61000-4-18 Damped Oscillatory 30MHz
F2 Slow Damped Osc. IEC 61000-4-18
F1: Set all standard acc. to standard
F2: Damped Osc 100 kHz IEC 61000-4-18 Damped Oscillatory 100 kHz
F3: Damped Osc 1MHz IEC 61000-4-18 Damped Oscillatory 1MHz
F4: Damped Osc 100kHz MF IEC 61000-4-18 Damped Oscillatory 100 kHz H-Field
F5: Damped Osc 1MHz MF IEC 61000-4-18 Damped Oscillatory 1MHz H-Field
F3 Ringwave Gen. 100kHz IEC 61000-4-12
F1: Set all standard acc. to standard
F2: Ringwave Gen. 100kHz IEC 61000-4-12 Ringwave 100kHz
