AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 62 / 80
10.
Maintenance
10.1.
General
The generator is absolutely maintenance-free by using a solid state semiconductor switch to generate transients
10.1.1.
Test set- up
When setting up the test national and international regulations
regarding human safety have to be guaranteed.
It is recommended to connect the simulator to the ground reference
plane of the test set-up.
The generators of the series 500, UCS, VCS, CSS, TSS, OCS and
CNI, can be linked together to a fully automotive test set-up.
The set-up communicates via the IEEE / GPIB bus and is controlled by
ISMIEC software. For setting up the system see the following figures:
Each generator can be operated individual as single equipment.
