Manual for Operation V 5.24 19 / 80
3.4.
Main Menu OCS 500N6F.x
Page 1
MAIN MENU
F1 Fast Damped Osc. IEC 61000-4-18
F2 Slow Damped Osc. IEC 61000-4-18
F3 Ringwave Gen. 100 kHz IEC 61000-4-12
F4 Damped Osc. 1MHz ext. IEC 60255-26
F7 : Service
F1
F2
F3
F4
F5
F6
F7
Page 2 Fast Damped Osc
SETUP Fast Damped Osc.
F1 Damped Osc. 3MHz IEC 61000-4-18
F2 Damped Osc. 10MHz IEC 61000-4-18
F3 Damped Osc. 30MHz IEC 61000-4-18
F1
F2
F3
F4
F5
F6
F7
Page 2 Slow Damped Osc
SETUP Slow Damped Osc.
F1 Damped Osc. 100 kHz IEC 61000-4-18
F2 Damped Osc. 1 MHz IEC 61000-4-18
F3 Damped Osc. 100 kHz MF IEC 61000-4-18
F4 Damped Osc. 1 MHz MF IEC 61000-4-18
F1
F2
F3
F4
F5
F6
F7
Page 2 Ringwave (See menu structure Chap 3.2)
Ringwave. IEC 61000-4-12
F1 Quickstart
F2 Standard test routines
F3 User test routines
F1
F2
F3
F4
F5
F6
F7
Page 2 Standard test routines Ringwave (See menu structure Chap 3.2)
Damped Osc 1MHz ext. IEC 60255-26
F1 Quickstart
F2 Standard test routines
F3 User test routines
F1
F2
F3
F4
F5
F6
F7
