AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 33 / 80
Quick start
Easy and very fast operation of all standard functions of the equipment. The latest simulator settings are stored
automatically and will be recalled when Quick Start is next selected.
Page 3
Damped Osc. 1MHz Quick start
Press CHANGE and the test parameters parameter can be changed.
Select the desired parameter with the related function key and change the value by turning the front panel knob.
The cursor allows the user to define the digit to be changed (fast or slow change).
Press START and the test starts immediately with the displayed test parameters.
The operator now can navigate with the Cursor from parameter to parameter. The blinking parameter can be
changed by turning the front panel knob.
Press ESC will bring the user back to the previous menu level.
All function keys except F2 (manual trigger) can Stop the test
routine.
Burst specification as pre IEC 61000-4-18
Td = 2 s
tr = not specified
f = 400/ s for 1 MHz and 40/ s for 100 kHz
