AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 18 / 80
3.3.
Main Menu OCS 500N6.x
Page 1
MAIN MENU
F1 : Damped Osc. 100 kHz IEC 61000-4-18
F2 : Damped Osc. 1MHz IEC 61000-4-18
F3 : Ringwave 100 kHz IEC 61000-4-12
F4 : Damped Osc. 100kHz MF IEC 61000-4-10
F5 : Damped Osc. 1MHz MF IEC 61000-4-10
F6 : Damped Osc. 1MHz ext. IEC 60255-26
F7 : Service
F1
F2
F3
F4
F5
F6
F7
F1 Damped Oscillatory 100 kHz
With function key F1 the user can select Damped Oscillatory 100 kHz as per IEC 61000-4-18. The test pulses
are oscillatory waves with a frequency of 100 kHz and a rise time of 75ns.
F2 Damped Oscillatory 1MHz
With function key F2 the user can select Damped Oscillatory 1MHz as per IEC 61000-4-18. The test pulses are
oscillatory waves with a frequency of 1MHz and a rise time of 75ns...
F3 Ringwave 100 kHz
With function key F3 the user can select the Ring Wave 100 kHz as per IEC 61000-4-12. The test pulses are
oscillatory waves with a frequency of 100 kHz and a rise time of 0.5s.
F4 Damped Oscillatory 100 kHz Magnetic Field
With function key F4 the user can select the Damped Oscillatory Magnetic Field Test as per IEC 61000-4-10. The
test pulses are the same as used under F1 Damped Oscillatory 100 kHz.
F5 Damped Oscillatory 1MHz Magnetic Field
With function key F5 the user can select the Damped Oscillatory Magnetic Field Test as per IEC 61000-4-10. The
test pulses are the same as used under F2 Damped Oscillatory 1MHz.
F6 Damped Oscillatory 1MHz Ext.
With function key F6 the user can select Damped Oscillatory 1MHz as per IEC 60255-26 with coupling to the
external coupling device CNV 508N4. The test pulses are oscillatory waves with a frequency of 1MHz and a rise
time of 75ns...
F7 Service
Setup and servicing routines are available.
