AMETEK CTS OCS 500 N6 series

Manual for Operation V 5.24 22 / 80

Page 4 General Change standard level

SETUP Change standard levels

V : 250 V – 2500 V

Level1 Level 2 Level 3

V V V Coupling

500V 1000V 2500 DIFF

F1, F2, F3 For each coupling (Differential mode and Common mode) a separate level can be settled.

The display shows the actual working mode.

F6 Selection Differential mode and Common mode

H-field: 10 A – 100 A

Level1 Level 2 Level 3

A A A

10A 30A 100A

F7 Status

This menu shows all device settings.

Table of Contents3
General5
Purpose5
Safety Label on the Device5
Standards Covered by OCS 500N6 / N6F Generators6
Models and Options6
Special Models7
Operating Functions8
OCS 500N6.X Models8
Front View OCS 500N6.X8
Rear View OCS 500N6.X10
OCS 500N6F Models12
Front View OCS 500N6F.X12
Rear View OCS 500N6F.X14
Operation16
Description of the Menus16
Menu Structure17
Main Menu OCS 500N6.X18
Main Menu OCS 500N6F.X19
Phase Synchronization in 3-Phase System20
Service21
Setup23
Test Equipment OCS 500 Nx24
Assembling OCS 500N624
Assembling OCS 500N6Fx25
Technical Data26
Slow Damped Oscillatory as Per IEC 61000-4-1826
Fast Damped Oscillatory as Per IEC 61000-4-1828
RINGWAVE Immunity Requirements as Per ANSI C 62.41 (IEC 61000-4-12)29
General Specifications OCS 500N6.X30
General Specifications OCS 500N6F.X31
Damped Oscillatory 100 Khz or 1 Mhz as Per IEC 61000-4-1832
Operation32
Quick Start33
Standard Test Routines34
User Test Routines36
Coupling Decoupling Network37
Coupling/Decoupling Network for Ac/DC Power Lines37
Coupling to Signal- and Datalines38
Ri Setting for Slow Damped Oscillatory Wave 100 Ω or 200 Ω39
Menu Damped Osc. 1Mhz EXT40
Coupling as Per IEC 60255 with CNV 508 N440
Quick Start41
Standard Test Routines41
User Test Routines43
Fast Damped Oscillatory 3 Mhz, 10 Mhz or 30 Mhz as Per IEC 61000-4-1844
Operation44
Quick Start45
Standard Test Routines46
User Test Routines48
Coupling Decoupling Network49
Coupling/Decoupling Network for Ac/DC Power Lines49
Coupling to Signal and Datalines49
Ring Wave50
Operation50
Quick Start51
Standard Test Routine52
User Test Routines55
Ringwave and Damped Oscillatory Pulse Generation56
Coupling Decoupling Network57
Coupling to Ac / DC Power Supply Lines57
Coupling to Signal- and Datalines58
Test Set-Up59
Damped Oscillatory Magnetic Field as Per IEC 61000-4-1060
General60
Menu Damped Osc. Wave 1 Mhz Magnetic Field (MF)61
Maintenance62
General62
Test Set- up62
Calibration and Verification63
Factory Calibration63
Guideline to Determine the Calibration Period of AMETEK CTS Instrumentation63
Calibration of Accessories Made by Passive Components Only63
Periodically In-House Verification63
Verification Ringwave64
Verification Parameter64
Verification Damped Oscillatory Wave65
Verification Parameter Slow Damped Oscillatory Wave65
Verification Setup66
Verification Parameter Fast Damped Oscillatory Wave67
Verification Damped Oscillatory Wave 100 / 1000 Khz Magnetic Field71
Verification Parameter71
Delivery Groups72
Basic Equipment72
Accessories and Options72
USB Interface74
Optical Interface74
Appendix75
Declaration of CE-Conformity75
OCS 500 N6- General Diagram77
OCS 500 N6F- General Diagram 1-Phase Devices78
OCS 500 N6F- General Diagram 3-Phase Devices79
OCS 500N6 1-Phase Operating with 3-Phase Devices80
