AMF S-311 - a) Knives Adjustment (LTT)




B
A
B

1,8 — 2 mm
14
18
20
17 16
15
16
15
20
14


A
2 — 3 mm

D
22
14
25
20
26
S-311
1-63
Released:01/2014
E-mail: service@amfreece.cz; webside: amfreece.com
Phone: +420 582 309 146; Fax: +420 582 360 606
E - STANDARD MACHINE ADJUSTMENT
a) knives adjustment - LTT
a.1. Loosen the screw
18
.
a.2. Turn the knife
7
in direction A and adjust the position of the
guide plate
15
so that the lower edge of the guide plate
15
is
aligned with knife edge
7
.
a.3. Turn the knife
7
in direction A and adjust the position of the
xingknife
6
to obtain no clearance between them. Adjust the
upperedgeofthexingknife
6
to be aligned with knife
7
.
a.4. Align the upper and lower spring
16
17
withxingknife
6
.
(Spring boss
16
facestowardsthexingknife
6
.)
a.5. Tighten the screws
18
.
a.6. Adjust the pin
20
to protrude 1.8 — 2 mm on the lower part of
the knife
7
.
a.7. Loosen two screws
25
.
a.8. Adjust the knife holder
26
withxingknife
6
in direction D so
thatthexingknife
6
touches the knife
7
in distance 2—3 mm
from the blade section (pin
20
isalignedwithxingknifeface
6
).
The larger distance, the bigger pressure on the blade.
a.9. Tighten the screws
25
.
Blade section
Contact section
Aling to edge
Blade face
