Appendix A — Test Records A-2 Test Records for Spectrum Analyzer Verification
MS2720T MM PN: 10580-00342 Rev. D A-33
MS2720T Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-61. Spectrum Analyzer DANL (Preamp Off)
Frequency
Start / Stop
RBW
(MHz)
VBW
(kHz)
Measured dBm
(MHz RBW)
Calculated dBm
(1 Hz RBW)
1Hz
Specification
For MS2720T with Opt. 709
10 MHz to 3.0 GHz 3 1 dBm dBm ≥ –146 dBm
>3.0 GHz to 8.0 GHz 3 1 dBm dBm ≥ –140 dBm
For MS2720T with Opt. 713, 720, 732 or 743
10 MHz to 4.0 GHz 3 1 dBm dBm ≥ –145 dBm
>4.0 GHz to 9.0 GHz 3 1 dBm dBm ≥ –142 dBm
>9.0 GHz to 13 GHz 3 1 dBm dBm ≥ –136 dBm
For MS2720T with Opt. 720
>13 GHz to 20 GHz 3 1 dBm dBm ≥ –138 dBm
For MS2720T with Opt. 732 or 740
>13 GHz to 32 GHz 1 1 dBm dBm ≥ –135 dBm
>32 GHz to 40 GHz 1 1 dBm dBm ≥ –127 dBm
Table A-62. Spectrum Analyzer Third Order Intercept
Third Order Intercept at
Center Frequency Measured Value Specification
2400.151 MHz dBm
2399.851 MHz dBm
Calculated TOI at 2400 MHz dBm ≥ +14 dBm
