A-3 Test Records for Options Verification Appendix A — Test Records
A-56 PN: 10580-00342 Rev. D MS2720T MM
Option 885 Mobile WiMAX RF Measurements
Channel Power Accuracy (10 MHz Bandwidth and 10 ms Frame Length)
MS2720T Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-117. RF Measurements, Mobile WiMAX Channel Power Accuracy Power Error (2600.5 MHz and
–15.0 dBm)
Measurement Measured Value Specification
Power Meter Reading dBm –15 dBm ± 0.2 dB
MS2720T Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
Table A-118. RF Measurements, Mobile WiMAX Channel Power Accuracy Power Error (2600.5 MHz and
–50.0 dBm)
Measurement Measured Value Specification
Power Meter Reading dBm –50 dBm ± 0.2 dB
MS2720T Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
Table A-119. RF Measurements, Mobile WiMAX Channel Power Accuracy Power Error (3600.5 MHz and
–15.0 dBm)
Measurement Measured Value Specification
Power Meter Reading dBm –15 dBm ± 0.2 dB
MS2720T Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
Table A-120. RF Measurements, Mobile WiMAX Channel Power Accuracy Power Error (3600.5 MHz and
–50.0 dBm)
Measurement Measured Value Specification
Power Meter Reading dBm –50 dBm ± 0.2 dB
MS2720T Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
To Next Page
