A-3 Test Records for Options Verification Appendix A — Test Records
A-34 PN: 10580-00342 Rev. D MS2720T MM
A-3 Test Records for Options Verification
Option 31 GPS Receiver
Option 809, 813, 820 Tracking Generator
Table A-64. Tracking Generator Frequency Accuracy
Table A-65. Tracking Generator Level Accuracy
MS2720T Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-63. Option 31, GPS Receiver Frequency Accuracy
Frequency Measured Value Error Specification
7 GHz GHz Hz ±175 Hz (±25 ppb) with “GPS Hi Accy”
7 GHz GHz Hz ±350 Hz (±50 ppb) with “Int Hi Accy”
Frequency Measured Value Error Specification
1 GHz GHz Hz ±1300 Hz (±1.3 ppm)
7 GHz GHz Hz ±9100 Hz (±1.3 ppm)
Note
The listed Amplitude Accuracy specifications apply when the instrument is being verified in an
environment between 20°C and 30°C after a 30 minute warm-up period. For an instrument that is not
being verified in a temperature controlled environment, but within a temperature range between 0°C
and 55°C and after a 60 minute warm-up, add ± 0.5 dB to the Amplitude Accuracy specification for
frequencies from 100 kHz to 18 GHz.
Test Level Measured Value Error Specification
50 MHz @ 0 dBm dBm dB ±1.5 dB
50 MHz @ -19.5 dBm dBm dB ±1.5 dB
50 MHz @ -40 dBm dBm dB ±1.5 dB
450 MHz @ 0 dBm dBm dB ±1.5 dB
450 MHz @ -19.5 dBm dBm dB ±1.5 dB
450 MHz @ -40 dBm dBm dB ±1.5 dB
