Chapter 1 — General Information 1-4 Replaceable Parts
MS2720T MM PN: 10580-00342 Rev. D 1-5
c. Note that MG3692A models require Option 15 to achieve power of +13 dBm. MG3692B and MG3692C models do not require
Option 15 to achieve +13 dBm power.
d. Note that the MG3700A requires that several factory custom test pattern files be installed into its memory.
1-4 Replaceable Parts
GPS Antenna Anritsu 2000-1410
Coaxial Cable BNC(m) to BNC(m), 50 ohm Any
Adapter K(f) to N(f), 50 ohms, Ruggedized Anritsu Model 71693-R
Table 1-4. List of Replaceable Parts (1 of 2)
Part Number Description
ND75313
e
MS2720T Main PCB Assembly with Option 9 for s/n < 1543111 or s/n 1544002,
1544004, 1544015, 1544026, 1544028, 1545047, and 1545050
ND75313
e
MS2720T Main PCB Assembly with Option 9 for s/n > 1543110 with the following
exceptions: s/n 1544002, 1544004, 1544015, 1544026, 1544028, 1545047, and
1545050
ND75315 MS2720T-0709 Spectrum Analyzer PCB Assembly for s/n < 1504014
ND81238 MS2720T-0709 Spectrum Analyzer PCB Assembly for s/n > 1504013
ND75316 MS2720T-0713 Spectrum Analyzer PCB Assembly
ND81240 MS2720T-0720 Spectrum Analyzer PCB Assembly for s/n < 1501076 and
s/n 1503029, 1503034, 1503175, 1503181, 1504076, 1505111, and 1505124
ND75317 MS2720T-0720 Spectrum Analyzer PCB Assembly for s/n > 1505146 and
s/n 1501076, 1503077, 1503185, 1504019, 1504029, 1504044, 1504046, 1504047,
1504082, 1504141, 1504144, 1504145, 1504147, 1504149, 1504151, 1504152,
1504157, 1504160, 1504165, 1505002, 1505003, 1505004,1505005, and 1505147
ND75318 MS2720T-0732 and MS2720T-0743 Spectrum Analyzer PCB Assembly for
MS2720T-0732 s/n < 1451132 and for MS2720T-0743 s/n < 1501051
ND81080 MS2720T-0732 Spectrum Analyzer PCB Assembly for s/n > 1451131
ND82204 MS2720T-0743 Spectrum Analyzer PCB Assembly for s/n > 1501050
ND75314 MS2720T GPS Receiver PCB (Option 31)
ND75319 MS2720T-0809 and MS2720T-0813 Tracking Generator
ND75320 MS2720T-0820 Tracking Generator
3-790-661 Gasket material for case edge
3-15-165 LCD Display for s/n < 1543111 or s/n 1544002, 1544004, 1544015, 1544026,
1544028, 1545047, and 1545050
3-15-174 LCD Display for s/n > 1543110 with the following exceptions: s/n 1544002, 1544004,
1544015, 1544026, 1544028, 1545047, and 1545050
ND73867 Touch Screen with Gasket (replaced by ND80480)
ND80480 Touch Screen with Gasket and Protection (replaced ND73867)
2000-1685-R Soft Carrying Case
