A-3 Test Records for Options Verification Appendix A — Test Records
A-58 PN: 10580-00342 Rev. D MS2720T MM
Option 885 Mobile WiMAX Demodulator
MS2720T Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-125. Demodulation, Mobile WiMAX Residual EVM (10 MHz Bandwidth and 10 ms Frame Length)
Frequency Power BW EVM (rms) Specification
2600.5 MHz –15 dBm 10 MHz % ≤ 3.0 %
2600.5 MHz –30 dBm 10 MHz % ≤ 3.0 %
3600.5 MHz –15 dBm 10 MHz % ≤ 3.0 %
3600.5 MHz –30 dBm 10 MHz % ≤ 3.0 %
Table A-126. Demodulation, Mobile WiMAX Frequency Error (10 MHz Bandwidth and 10 ms Frame Length)
Frequency Power Frequency Error Specification
2600.5 MHz –50 dBm Hz ± 52.01 Hz (± 0.02 ppm)
5600.5 MHz –50 dBm Hz ± 112.01 Hz (± 0.02 ppm)
Table A-127. Demodulation, Mobile WiMAX Residual EVM (5 MHz Bandwidth and 5 ms Frame Length)
Frequency Power BW EVM (rms) Specification
2600.5 MHz –15 dBm 10 MHz % ≤ 3.0%
2600.5 MHz –30 dBm 10 MHz % ≤ 3.0%
3600.5 MHz –15 dBm 10 MHz % ≤ 3.0%
3600.5 MHz –30 dBm 10 MHz % ≤ 3.0%
Table A-128. Demodulation, Mobile WiMAX Frequency Error (5 MHz Bandwidth and 5 ms Frame Length)
Frequency Power Frequency Error Specification
2600.5 MHz –50 dBm Hz ± 52.01 Hz (± 0.02 ppm)
5600.5 MHz –50 dBm Hz ± 112.01 Hz (± 0.02 ppm)
