Appendix A — Test Records A-3 Test Records for Options Verification
MS2720T MM PN: 10580-00342 Rev. D A-51
Option 884, EVDO RF Measurements
MS2720T Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-103. RF Measurements, At 870.03 MHz, –50 dBm Level, 921.6 kps 8PSK Modulation
Measurement Measured Value Specification
Power Meter Reading dBm –50 dBm ± 0.2 dB
MS2720T Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
Table A-104. RF Measurements, At 1930.05 MHz, 0 dBm Level, 38.4 kps QPSK Modulation
Measurement Measured Value Specification
Power Meter Reading dBm 0 dBm ± 0.2 dB
MS2720T Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
Table A-105. RF Measurements, At 1930.05 MHz, –50 dBm Level, 2457.6 kps 16QAM Modulation
Measurement Measured Value Specification
Power Meter Reading dBm –50 dBm ± 0.2 dB
MS2720T Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
Table A-106. RF Measurements, At 1930.05 MHz, –50 dBm Level, Idle Slot
Measurement Measured Value Specification
Power Meter Reading dBm –50 dBm ± 0.2 dB
MS2720T Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
