Anritsu Spectrum Master MS2720T - Option 881 WCDMA and HSDPA RF Measurements

Appendix A — Test Records A-3 Test Records for Options Verification
MS2720T MM PN: 10580-00342 Rev. D A-41
Option 881 WCDMA and HSDPA RF Measurements
MS2720T Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-82. RF Measurements, Sensor A and Sensor B Readings, Components Characterization
Frequency PMA.10 PMB.10 Delta 1 (
Δ1) PMA.10C PMA.18 ATT.18
881.5 MHz dBm dBm dBm dBm dBm dB
Table A-83. RF Measurements, Power Level Setting, Components Characterization
Frequency
MG3700A.10
Setting
MG3700A.28
Setting PMA – 10 PMA – 20
881.5 MHz dBm dBm dBm dBm
Table A-84. RF Measurements, WCDMA Absolute Power Accuracy
Test Level Measured Power Error Specification
+28 dBm dBm dB ± 1.25 dB
+10 dBm dBm dB ± 1.25 dB
–10 dBm dBm dB ± 1.25 dB
–20 dBm dBm dB ± 1.25 dB
Test Level dBm dB ± 1.25 dB
Table A-85. RF Measurements, WCDMA Occupied Bandwidth (OBW)
Frequency Power Meter Reading OBW Specification
881.5 MHz dBm MHz 4.2 MHz ± 100 kHz
1962.5 MHz dBm MHz 4.2 MHz ± 100 kHz
2680.5 MHz dBm MHz 4.2 MHz ± 100 kHz
