Anritsu Spectrum Master MS2720T - Option 884, EVDO RF Measurements (Continued; Option 884 EVDO Demodulator

A-3 Test Records for Options Verification Appendix A — Test Records
A-52 PN: 10580-00342 Rev. D MS2720T MM
Option 884, EVDO RF Measurements (Continued)
Option 884 EVDO Demodulator
MS2720T Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-107. RF Measurements, At 870.03 MHz, –10 dBm Level, Idle Slot
Measurement Measured Value Specification
Power Meter Reading dBm –10 dBm ± 0.2 dB
MS2720T Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
Table A-108. Demodulation, At 870.03 MHz, –50 dBm Level, 921.6 kps 8PSK Modulation
Measurement Measured Value Specification
Frequency Error Hz ± 10 Hz
Rho Pilot 0.99 ≤ x ≤ 1
Tau μs± 1μs
Table A-109. Demodulation, At 1930.05 MHz, 0 dBm Level, 38.4 kps QPSK Modulation
Measurement Measured Value Specification
Frequency Error Hz ± 10 Hz
Rho Pilot 0.99 ≤ x ≤ 1
Tau μs±1μs
