Appendix A — Test Records A-3 Test Records for Options Verification
MS2720T MM PN: 10580-00342 Rev. D A-57
Option 885 Mobile WiMAX RF Measurements (Continued)
Channel Power Accuracy (5 MHz Bandwidth and 5 ms Frame Length)
MS2720T Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-121. RF Measurements, Mobile WiMAX Channel Power Accuracy Power Error (2600.5 MHz and
–15.0 dBm)
Measurement Measured Value Specification
Power Meter Reading dBm –15 dBm ± 0.2 dB
MS2720T Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
Table A-122. RF Measurements, Mobile WiMAX Channel Power Accuracy Power Error (2600.5 MHz and
–50.0 dBm)
Measurement Measured Value Specification
Power Meter Reading dBm –50 dBm ± 0.2 dB
MS2720T Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
Table A-123. RF Measurements, Mobile WiMAX Channel Power Accuracy Power Error (3600.5 MHz and
–15.0 dBm)
Measurement Measured Value Specification
Power Meter Reading dBm –15 dBm ± 0.2 dB
MS2720T Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
Table A-124. RF Measurements, Mobile WiMAX Channel Power Accuracy Power Error (3600.5 MHz and
–50.0 dBm)
Measurement Measured Value Specification
Power Meter Reading dBm –50 dBm ± 0.2 dB
MS2720T Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
