Anritsu Spectrum Master MS2720T User Manual

Chapter 2 —Fixed WiMAX Signal Analyzer 2-10 Measurements Menu
WiMAX MG PN: 10580-00236 Rev. D 2-23
Demodulator Menu (Continued)
EVM vs Sub Carrier: Press this submenu key to display the EVM (rms)
values versus OFDM subcarriers. The pilot subcarriers are shown in
orange.
EVM vs Symbol: Press this submenu key to display the EVM (rms)
values versus OFDM symbols.
Modulation Summary: Press this submenu key to display a summary
table of all of the modulation-related numerical measurement results:
• RCE (rms) in dB
• RCE (pk) in dB
• EVM (rms) in %
• EVM (pk) in %
• Freq Error in Hz
• Freq Error (ppm)
• Carrier Frequency in Hz
• Base Station ID
Back: Press this submenu key to return to the “Measurements Menu”
on page 2-20.
Figure 2-19. Fixed WiMAX Demodulator Menu (2 of 2)
Reference Points
Off On
Back
Back
Demodulator
Constellation
Spectral Flatness
EVM vs
Sub Carrier
EVM vs
Symbol
Modulation
Summary
Constellation
