A multiple command entry is only valid where specified. Where a multiple command entry is allowed,
each command MUST be separated with a space “h20” (HEX DECIMAL). Each command is completed
with a [CR] or [CR] [LF]. Although there is no local echo, either [CR] or specified response should come
back from the receiver after confirming the correct command. If no response has been gained after a
short while, the receiver has failed to receive the command properly. Send a [CR] then re-send the
command. Should problems persist, check your connections and try reducing the RS232 baud rate.
AR8600 remote indication: When the AR8600 has received a command via the RS232C port the
receiver’s LCD will display the ¤ symbol. The AR8600 will appear frozen while RS232 operation is in
progress. To return operation to the radio keyboard, on the AR8600.
Section 17-1, 17-2
17-2 Brief command index (RS232)
^A Remote ID
AF Automatic Frequency Control
AM Bandscope analyser
AP Auto power off
AS Search auto store
AT Attenuator
AU Auto mode
BM Scan bank linking
BP Search bank protect
BS Search bank linking
CF Bandscope centre frequency
CN CTCSS operation
DA Dial (VFO) audio squelch
DB Dial (VFO) level squelch
DC Bandscope date centre frequency
DD Dial (VFO) delay
DP Dial (VFO) pause
DS Bandscope ****
DT Display frequency (on/off)
EX Exit RS232
GA Select scan
GD Release select scan channels
GM Scan parameter selection
GR Select scan recall
GS Search parameter selection
GV VFO status list
LB LCD contrast
LC Frequency & level status
LM Signal meter reading
LS Tone eliminator frequency
(requires optional TE8200 slot card)
MA List a block of memory channels
MC Monitor control (forced squelch)
MD Receive mode
MF Bandscope set marker frequency
MP Set memory channel pass
MQ Delete memory channel or bank
MR Memory recall
MS Scan mode
MW Memory bank resizing
MX Memory write
NL Noise limiter
OF Frequency offset
OL Set and list frequency offset
OM Opening message
PC Protect memory channel
PD Delete pass frequency
PH Bandscope peak hold
PP Priority channel
PQ Wait time for LC2
PR List pass frequencies
PW Write search pass frequency
QM Quick memory
QP Power off
QS Delete search bank
RF Set receive frequency
RX Respond with current data
SA Search audio squelch
SB Search level squelch
SC Voice invertor frequency
(requires the optional VI8200 slot card)
SD Search hold / delay time
SE Set search data
SH Set offset step
SI Voice invertor on/off
(requires the optional VI8200 slot card)
SL Lower search frequency limit
SM Start select scan
SP Search pause time
SR Recall search parameters
SS Start search
ST Tuning step size
SU Upper search frequency limit
SW Bandscope span width
TB Set text description for bank
TI Set priority interval
TM Memory text
TS Text search
TT Search bank text
VA Set VFO A
VB Set VFO B
VF Select 1-VFO mode
VL Beep volume
VR Firmware version
VS VFO search
VT VFO auto-store
VV VFO scan
WM Write protect bank
WP Write protect enable
XA Scan audio squelch
XB Scan level squelch
XD Memory scan delay time
XM Mode scan
XP Scan pause setting
UP/DOWN Tuning arrows
