POS MV V4 User Guide

Theory of Operation

B-20

Since the dynamics of a large vessel will not significantly excite the

transient behaviour of the filter, configure the heave filter to achieve a

small percentage steady state error at the expense of a long settling

time.

Table 36 describes the variations of steady state heave error and settling time

with changes in damping ratio and bandwidth.

Figure 69 through Figure 72 on

pages

B-21 through B-24 respectively show plots of steady state heave error

and transient behaviour for different combinations of heave filter parameters.

Table 36

: Effects of Modifying Heave Filter Parameters

Heave Filter Tuning

Steady State

Error

Settling Time

Increase Increase Decrease

Damping ratio

Decrease Decrease Increase

Increase Decrease Increase

Heave bandwidth

Decrease Increase Decrease
