Applied Biosystems 7500 User Manual

Appendix A
Replacing the Instrument Fuses
122 Applied Biosystems 7300/7500/7500 Fast Real-Time PCR System Installation and Maintenance Guide
Notes
Replacing the Instrument Fuses
FIRE HAZARD. For continued protection against the risk of fire,
replace fuses only with listed and certified fuses of the same type and rating as those
currently in the instrument.
Time Required 30 minutes
Materials
Required
Replacing the
Fuses
1. Turn off the instrument, then unplug it.
2. Using a flat-head screwdriver, unscrew and remove the fuse holders from the
instrument.
Powder-free
gloves
Flathead
screwdriver
Fuses (2), 12.5A,
250V, 5 x 20 mm
Safety
glasses

Applied Biosystems 7500 Specifications

General

Detection Method	Fluorescence
Sample Capacity	96-well plate
Thermal Cycler	Yes
Temperature Uniformity	±0.5°C
Type	Real-Time PCR System
Thermal Accuracy	±0.25°C
Detection Channels	5
Weight	45 kg
Power Requirements	100-240 V, 50/60 Hz
Dynamic Range	9 logs
Reaction Volume Range	10-100 µL
Temperature Range	4°C to 100°C
Thermal Cycler Block	96-well
Software	SDS Software
Detection	Multiplex (up to 5 colors)
