Octave Configuration Guide 15
5 Output Settings
Overview
The Output Settings tab is for configuring the output per the target output
module.
This chapter describes the configuration settings per the target output types
and modes as follows:
• No Output
• Pulses
• 4-20 mA
• 4-20 mA & Pulse (only 4-20 mA, or 4-20 mA & Pulse)
• Encoder (only encoder, only pulses, or encoder + pulse)
• Extended Encoder (only encoder, only pulses, or encoder + pulse)
• CZ Module
• Modbus (only Modbus, or Modbus + pulse)
• Mbus (only Mbus, or Mbus + pulse)
At the bottom of the page for each type of output configuration there are three
controls: Save, Revert and Record.
After you complete output configuration, tap Save to keep your changes. Tap
Revert to return the output settings to the last saved configuration.
And if needed, tap Record to create a manual output file per the recording
configuration in Application Settings.
