Arad Octave User Manual

Octave Configuration Guide 5
Connecting the NFC reader
To set up communication between the Arad Smart Meters application and the
Sonata Pulse water meter, you need to attach the NFC reader.
IMPORTANT: When the NFC reader and the meter are in a connected state,
meter output is disabled. Therefore, initial configuration of the meter should be
completed before the meter is installed.
1. Fasten the NFC reader to the plastic adapter (A) and
clasp the adapter + NFC reader to the Octave display (B).
2. Double-click the Arad Smart Meters shortcut on the desktop to start the
software.
3. Log in. See Logging in to Arad Smart Meters.
IMPORTANT: Before removing the NFC reader from the meter always tap
Disconnect. Otherwise the meter remains in a connected state. When the
meter is in a connected state, meter output is disabled.

Arad Octave Specifications

General

Protection Class	IP68
Type	Ultrasonic flow meter
Communication	M-Bus
Pressure Rating	16 bar
Power Source	Internal battery
