32 The Setup Menus
7.2 Setup Menus
No. Setup Menus Setup Items
1 Set Main RS-232? Main RS-232 Port Parameters and Broadcast
2 Set Local Hour? Set Local Offset, Daylight Saving mode
3 Set Out-Of-Lock? Set Time Interval Before Alarm
4 Set Back Light? Set to ON, OFF or AUTO
5 Set System Delays? Set Antenna Cable Delay in Nanoseconds
6 Set Prog. Pulse? Set Mode, Pulse Width and Time Zone
7 Set IRIG Time Data? Set IRIG-B Time Zone and IEEE-1344
8 Set Event/Deviation? Set for Event, or 1–PPS Deviation
9 Set Auto Survey? Set Survey mode
10 Set Position Hold? Set ON or OFF
11 Set Option Control? Set Main board and Aux. board options
Table 7.1: Front-Panel Setup Menus
7.2.1 Default Firmware Settings
When shipped from the factory, and unless specified otherwise, all models will be configured with
default settings. Most users elect to modify the clock settings to fit their locale and desired opera-
tion. Default settings are listed in Table 7.2.
Menu Item Default Menu Item Default
Main RS-232 9600, 8, N, 1 Local Offset & DST none, OFF
Out-of-Lock 01 minute Backlight Auto
System Delays 60 ns Prog Pulse Sec. per Pulse
IRIG-B Time Data UTC, 1344 OFF Event/Deviation 1 PPS Deviation
Auto Survey Power On Survey Position Hold ON
Option Control None – –
Table 7.2: Default Firmware Settings
7.2.2 Numeric Data Entry Mode
Numeric data entry mode is activated anytime you enter a menu that requires a change in numerical
value and press either the UP or DOWN key to change the digit value. When in this mode, the
function of the SETUP and ENTER keys change to give left and right cursor control.
